NEW ACT MEGALODON LH2 TRANSPORT TRAILER 18,234 GALLONS, 155 PSIG, LIQUID HYDROGEN TANDEM SEMI-TRAILER

ACT Megalodon 18,234 Gallon Liquid Hydrogen (LH2) Transport Trailer – 155 PSIG – Tandem Semi-Trailer

This Applied Cryo Technologies (ACT) Megalodon liquid hydrogen (LH2) transport trailer, Model LH2-182-155-P-T-TD, is an 18,234-gallon, vacuum-insulated cryogenic tandem semi-trailer with a maximum allowable working pressure (MAWP) of 155 PSIG. Designed for over-the-road liquid hydrogen transportation, the trailer has a maximum gross vehicle weight of 80,000 lbs and a maximum permissible liquid weight of 9,923 lbs at a 17 PSIG fill density. The trailer is designed to meet ASME Section VIII, Division 1 and 49 CFR 178.338 (MC-338) requirements and complies with California’s 40-foot kingpin-to-rear-axle requirement.

Technical Specifications

Manufacturer: Applied Cryo Technologies (ACT)

Model: LH2-182-155-P-T-TD (Megalodon)

Product Service: Liquid Hydrogen (LH2)

Configuration: Vacuum-Insulated Tandem Semi-Trailer

Maximum Allowable Working Pressure (MAWP): 155 PSIG (10.69 Bar)

Warm Water Capacity: 18,234 US Gallons (69,023 Liters)

Cold Water Capacity @ Vent Inlet: 18,053 US Gallons (68,338 Liters)

Maximum Permissible Weight of Liquid (17 PSIG Fill Density): 9,923 Lbs (4,501 Kg)

Payload: Approximately 1,905,000 SCF (Based on 17,800 Lb Sleeper)

Tare Weight: 46,123 Lbs (20,921 Kg) ±3%

Maximum Gross Vehicle Weight (MGVW): 80,000 Lbs

Normal Evaporation Rate (NER): 0.5% Per Day

Insulation Type: ACT Super Insulation (SI) – Vacuum Insulated

Design Codes: ASME Section VIII, Division 1; 49 CFR 178.338 (MC-338)

Regulatory Compliance: California 40’ Kingpin-to-Rear-Axle (KPRA) Requirement

Location: Houston, TX

Construction & Features

Design: Over-the-Road Liquid Hydrogen Transport Semi-Trailer

Orientation: Horizontal

Trailer Configuration: Tandem Axle

Insulation: ACT Super Insulation (SI) with Vacuum-Insulated Construction

Cryogenic Service: Liquid Hydrogen (LH2)

Transport Compliance: MC-338 Cryogenic Cargo Tank Requirements

Pricing

Contact for purchase pricing and availability. Lease and lease-to-own options are available.

Pre-Purchase Inspections

We welcome pre-purchase inspections during normal business hours, by appointment only. If you’re planning to fly in to view or inspect the equipment in person, we are happy to arrange that with proper notice.

Shipping Arrangements

This unit is sold EXW (Ex Works) Houston, TX. The buyer is responsible for arranging and paying for all shipping and freight.

This unit is a tandem semi-trailer with a tare weight of 46,123 lbs. The buyer is responsible for arranging the tractor, driver, and all transportation.
